Product Solutions for Cement Industry


Cement is the world’s most important construction materials. Cement production, generally can be divided into raw material grinding, burning. Cement is made using three processes – raw material grinding limestone and clay and other raw materials for the mill grinding process.


Increasing production and quality demands in the cement industry have resulted in the need for improvement in the speed and accuracy of quality control results. This need has been addressed by many technological advances in quality control automation in recent years. The complete system for controlling a modern cement plant with integrated automation systems ensures increased product quality and efficiency while being environmental sound. Efficient information channels, process management, digital field bus systems and the sensors themselves are all becoming increasingly important.

Applicable Products

Great Plains Industries


A. G Series Turbine Meter


General Specifications:


  • Accuracy: +/- 0.5% of reading
  • Flow Range: 0.6 to 600 GPM (3.0 to 2,271 L/min)
  • Temperature: -450 to 300 deg F [-268 to 426 deg C]
  • Pressure: 2,500 to 5,000 PSI (170 to 340 Bar)
  • Meter Sizes: 1/2″ to 3” (15 to 80 mm)
  • Meter Body Materials: Stainless Steel
  • Fitting Connections: NPT, BSP, Sanitary and ANSI Flange

B. G2 Series Turbine Meter


General Specifications:


  • Accuracy: +/- 1.5% to 0.75% of reading (Depending on Pipe Size)
  • Flow Range: 1.0 to 200 GPM (3.8 to 760 L/min)
  • Temperature: -40 to 250 deg F, 140 deg F w/ display [-40 to 121 deg C, 60 deg C w/ display]
  • Pressure: 1,500 to 3,000 PSI (102 to 207 Bar)
  • Meter Sizes: 1/2″ to 2” (15 to 50 mm)
  • Meter Body Materials: Aluminum, Stainless Steel and PVDF
  • Fitting Connections: NPT, BSP Thread, Sanitary Flange and True Union

C. TM Turbine Meter


General Specifications:


  • Accuracy: +/- 3% of reading
  • Flow Range: 10 to 600 GPM (3.8 to 2271 L/min)
  • Temperature: 32 to 140 deg F (0 to 60 deg C)
  • Pressure: 225 PSI at 73 deg F (15.3 Bar at 23 deg C)
  • Meter Sizes: 1/2″ to 4” (15 to 100 mm)
  • Meter Body Materials: PVC Plastic
  • Fitting Connections: NPT, BSP, #150 ANSI or DIN Flange and Spigot

D. A1 Series Rate & Total Meter


a. MODEL: A025, A100 (1in.)


  • Accuracy: +/- 1.5% of reading
  • Flow Range GPM (L/min): 0.3-300 (1-190)
  • Temperature: -40 to +250 deg F (-40 to +121 deg C)
  • Temp. with Computer: 0 to +140 deg F (-18 to +60 deg C)
  • Pressure: 300 PSI (21 Bar)
  • Meter Sizes: 1″ to 2″ (25 to 50 mm)
  • Meter Body Materials: Aluminum and Nylon
  • Fitting Connections: NPT and BSP

b. MODEL: A200 (2 in.) N025 & N100 (1 in.)


  • Accuracy: +/- 1.5% of reading
  • Flow Range GPM (L/min): 0.3-50 (1-190)
  • Temperature: -40 to +250 deg F (-40 to +121 deg C)
  • Temp. with Computer: 0 to +140 deg F (-18 to +60 deg C)
  • Pressure: 150 PSI (10.2 Bar)
  • Meter Sizes: 1″ to 2″ (25 to 50 mm)
  • Meter Body Materials: Aluminum and Nylon
  • Fitting Connections: NPT and BSP

E. Economy Meters


a. MODEL: 01N Turbine


  • Accuracy: +/- 5.0% of reading
  • Flow Range GPM (L/min): 3-30 (10-100)
  • Temperature: 14 to 131 deg F (-10 to 55 deg C)
  • Pressure: 150 PSIG (10.2 Bar)
  • Meter Sizes: 1″ (25 mm)
  • Meter Body Materials: Aluminum, Nylon and PBT Polyester
  • Fitting Connections: NPT and BSP


b. MODEL: 01A Turbine


  • Accuracy: +/- 5.0% of reading
  • Flow Range GPM (L/min): 3-30 (10-100)
  • Temperature: 14 to 130 deg F (-10 to 54 deg C)
  • Pressure: 300 PSIG (21 Bar)
  • Meter Sizes: 1″ (25 mm)
  • Meter Body Materials: Aluminum, Nylon and PBT Polyester
  • Fitting Connections: NPT and BSP

c. MODEL: FM-300 H/R


  • Accuracy: +/- 2.0% of reading
  • Flow Range GPM (L/min): 2-20 (7-75)
  • Temperature: 15 to 130 deg F (-9 to 54 deg C)
  • Pressure: 50 PSIG (3.4 Bar)
  • Meter Sizes: 1″ (25 mm)
  • Meter Body Materials: Aluminum, Nylon and PBT Polyester
  • Fitting Connections: NPT and BSP

F. DP Series Insertion Impeller Meter


General Specifications:


  • Accuracy: +/- 1.5% of reading
  • Flow Range: 4.0 to 780,000 GPM (0.015 to 2940 m/min) Depending on pipe size
  • Flow Velocity Range: 1 to 33 ft/s (0.3 to 10 m/s)
  • Temperature: -40 to 300 deg F (-40 to 1500 deg C)
  • Pressure: 1,200 PSI (80 Bar)
  • Meter Sizes: 1-1/2″ to 100” (40 to 2500 mm)
  • Meter Body Materials: Stainless Steel

G. QStar Ultrasonic Meter


General Specifications:


  • Accuracy: Up to +/-1% of reading
  • Flow Velocity Range: +/-98.42 t/sec (30 m/s)
  • Operating Temperature: -4 to 140 deg F (-20 to 60 deg C)
  • Transducer Temperature: -40 to 300 deg F (-40 to 150 deg C)
  • Pipe Sizes: 1/2″ to 240” (10 to 6000 mm)

Fluid Components International


Fluid Components International solves flow and level measurement applications for industrial process and plant applications using patented thermal dispersion flow measurement technologies; With more than 40 years’ experience and the world’s largest installed base of thermal dispersion instruments, you can count on FCI to know your application and have proven solutions that will save you time and expense.

A. ST50 Mass Flowmeter (Insertion Type)


General Specifications:

  • Line Size Compatibility: 2” to 24” (51 to 610 mm)
  • Key Features & Applications:
    • Easy to Install
    • Easy to Specify
    • Small, Compact Package
    • Air and Nitrogen Applications
    • Dual Analog Outputs
    • Ideal for Aeration and Larger Compressed Air Lines
  • Display: Flow Rate & Temperature Measurement (standard), Total Flow (Optional)
  • Flow Range: 0.75 SFPS to 400 SFPS [0.2 NMPS to 122 NMPS]
  • Turndown Ratio: 100:1
  • Accuracy: +/- 1% rdg, 05% FS
  • Repeatability:+/- 0.5% rdg
  • Temp (max operating): 0 to 250 deg F (-18 to 121 deg C)
  • Pressure (max operating): 500 psig [34 bar (g)]
  • Flow Element Wetted Materials: Stainless Steel with Hast-C tips
  • Flow Element Construction: Press Fit
  • Transmitter Output (Standard): (Dual) 4-20 mA; RS 232C
  • Transmitter Output (Optional): 0-1 kHz Pulse of Total Flow
  • Integral or Remote Mounting
  • Power Supply: AC, DC
  • Enclosure: Metal, NEMA 4X, IP67
  • Agency Approvals: FM, CSA, ATEX, CPA, CE, PED.
  • Other Features: Wireless IR Link

B. FLT93B (Flow & Level Switch)


General Specifications:

  • Line Size Compatibility (in flow applications): 1” to 100” (25 to 2500 mm)
  • Key Features & Applications:
    • General Purpose
    • Dual, Heavy-duty Relay Outputs
  • Flow Range-Air/Gas: 0.25 FPS to 120 FPS [0.08 MPS to 37 MPS]
  • Flow Range-Liquids (Water/Water based): 0.01 FPS to 3.0 FPS [0.003 MPS to 0.9 MPS]
  • Flow Range-Liquids (Hydrocarbon based): 0.01 FPS to 5.0 FPS [0.003 MPS to 1.5 MPS]
  • Flow Accuracy: +/- 5% rdg; +/-2% of Setpoint
  • Flow Repeatability:+/- 0.5% rdg
  • Level Accuracy: +/-0.25 inch [+/-6.4 mm]
  • Level Repeatability: +/-0.125 inch [+/-3.2 mm]
  • Temperature Compensation (standard)
  • Sensor Operating Temp Range: -40 to 350 deg F [-40 to 177 deg C]
  • Sensor Operating Pressure: 2,350 psig [162 bar (g)]
  • Flow Element Wetted Materials: Stainless Steel
  • Flow Element Construction: All Welded
  • Transmitters Outputs/Control Circuit: Dual SPDT or Single DPDT Relays, 6A DC Voltage Output for Calibration, DC Voltage of Temperature
  • Power Supply: AC, DC
  • Enclosure: Metal, NEMA 4X, IP66
  • Agency Approvals (system): FM, CSA, ATEX, CRN, IEC, CE, PED
  • Other Features, Options: Precheck Fail Guard



From transducers for belt- or front-end loader scales, bulk level and point monitoring to individual flow rate measurement for bulk and solids – in the Control Division REMBE® offers a wide range of measuring systems. The Control Division has established itself worldwide offering individual measuring systems for silos, mixers, tanks and other kinds of containers and machinery.

A. UNIBAND Beltscale


35 years of experience and a continuous dialogue with our customers enabled us to optimise our belt scale UNIBAND®. Our products distinguish themselves by innovative technique „Made in Germany” and comprehensive service. Our belt scale has been setting standard in running operation output measurements for years. The customer benefits from top precision measurement and the flexible range of applications.




The belt scale records the continuous material flow by means of the weighing with the incorporated load cell. The weighing station converts the vertical pressure into a horizontal tensile force via two maintenance-free pivot bearings. The tensile force is transmitted to the load cell sensor and converted by this into an electrical voltage signal. The weighing unit connected to the sensor evaluates the weight signal in relation to the belt speed tachometer and displays the idler transport rate in „t/h” (tons per hour) and the selected count in „t” (e.g. tons per day, tons per month or tons per year).




  • continuous measurement in both stationary and mobile conveying equipment
  • full-bridge strain gauge transducer with mechanical overload protection
  • easy adjustment due to comparable weighing


Your benefits:

  • quick installation, low in height
  • robust stainless steel construction
  • reduced cost of ownership

B. C- Lever

C- Lever

C-LEVER® direct (CLD) is the result of the permanent improvement of innovative REMBE® technologies. In close cooperation with the university of applied science in Düsseldorf, the C-LEVER® measurement procedure has been optimized to be an extremely precise and absolutely reliable measuring system for bulk and solids. The consistent pursuit of the goals that were set has led to a measurement procedure based on centrifugal force that is unique in the world and for which a patent is pending.


The C-LEVER®direct (CLD) flowmeter is characterized by the highest measurement accuracy. The various series are suited to the widest variety of applications – from truck pre-loading to controlling and dosing tasks in the bulk goods processing industry. The compact design and the low overall height enable space saving applications whilst reducing time during installation.


Advantages at a glance:


  • transparency of stock levels and costs
  • reliable production control
  • optimised quality assurance
  • less truck traffic on the factory site
  • particle-preserving method of measuring bulk quantities



A. SA Capacitance Level Switch


The capacitance level sensor measuring principle is based on the “capacitance effects”, when this level sensor is set on a silo, it will be formed a condenser between the detector electrode and the silo wall. The capacitance of this condenser varies proportional to the change of material specific inductivity (DK value) of the material stored in the silo, when the more material substances increased in the silo, the more capacitance value added simultaneously, then it will let his interior circuit “s resonant signal to create a bigger amplitude, and such a signal amplitude become more or less than factory default threshold value, the relay device will be energized.





  • No moving parts inside the device, it will be not affected by friction, which are suitable for powder or liquid application.
  • Various models are suitable for different application.
  • Operating temperature -20 ~ 200°C, Max. 800°C.
  • The sensitivity, which includes 10pf, 20pf and 40pf, is adjustable.
  • With timing delay design, timing adjustable range 0 ~ 6 seconds.
  • Voltage: 110V/220VacC or 24Vdc
  • Output: NPN transistor, 5A/250Vac and 5A/240Vac SPDT contact.
  • Standard connecting screw 1″ NPT, special specification are acceptable.
  • Enclosure protection IP65 or explosion-proof.
  • SA-75U Zener barriers inside provide intrinsic safety (Ex ia IIC) to SA17 ( ) D type level switch.




As Capacitance Level Switch has no moving parts inside the device, it will not be affected by friction. It is suitable for powder or liquid application easy to install. The customer can choose the types for his requirements.


a. Standard Type (SA110 & SA111 A/B/C)

Suitable for general use.


  1. Hi-Temp Type (SA120 & SA128 A/B/C)

Suitable for high temperature environment.


  1. Anti-Corrosion Type (SA130 & SA132 A/B/C)

Suitable for corrosive environment.


d. Remote Probe Type (SA140 A/B/C)

For use with vibrator equipped with tank.


e. Wire-Probe Type (SA150 A/B/C)

Suitable for silo or large-size tank.


f. Plate-Probe Type (SA160 A/B/C)

Suitable for granules and at lower position of tank side.


g. Explosion-Proof Type (SA270 – SA279)

Ex dia II C T4-T6, DIP A21 TA,T3-T6


h. Explosion-Proof Type (SA370 – SA378)

Ex ia IIC T3-T6

Equipped with SA-75U signal conditioner can be used in hazardous areas.


i. Anti-Static Type (SA180 & SA181 A/B/C)

Suitable for electrostatic environment

(It won’t be damaged by the electrostatic discharge)

B. EB RF-Capacitance Level Transmitter


Capacitance Level Indicator: Utilizes the capacitance formed between the sensing probe and the metallic vessel wall. A high frequency sine-wave is applied between the probe and the vessel wall. A change of the medium level will induce a change in the current of the applied sine wave. From Z=1/2pfc, when the capacitance in the vessel increase, impedance will decrease and current will increase. Vice-versa, when the capacitance in the vessel is small, the impedance will increase and current will decrease accordingly



  • Suitable for high temperature, high pressure and corrosive environment.
  • Not affected by noisy, dusty, misty and changes in the temperature.
  • No blind distance, ideal for different tanks.
  • Economic for large tanks
  • 4-20mA output compatible for most control systems and meters

C. EE Electromechanical Level Measuring System


EE200 series Electro-Mechanical Level Measuring System is consisted of plumb, cable wire, measuring pulley, position sensor, and control board. When measuring, the sensing weight will drop down and cable wire will rotate the measuring pulley. Position sensor and control board will calculate the distance of travel of the sensing weight(medium level) based on how many rotations measuring pulley accomplishes.




  • Measuring result immune from the interference of environment such as sound waves, dust, capacitance, or temperature change.
  • User-friendly with microprocessor-based design.
  • High level and low level alarm.
  • LCD Dot matrix: 8 x 2.
  • Analog output: 4-20mA dc.
  • Pulse output: Transistor output(NPN/PNP), Relay output(3A/250Vac)
  • Cable Break Alarm: System will detect cable broken during measuring.
  • Plumb Buried Alarm: System will detect plumb buried by the medium.
  • Start Modes: auto start, manual start, intelligent start, and external triggered start.
  • Intelligent Start: Measuring interval is inverse proportional to medium level.
  • Auto Return Setup: Prevent sensing weight from buried or sliding into the tank pivot and avoid damage facility equipment while tank is empty.
  • Material Fill-Up Protection: Reduce the possibility of plumb being buried.
  • Measuring range of 30m (Standard), max. up to 40 m.
  • RS485 MODBUS communication protocol.
